Meiji Techno FT192 150W Annular Fiber Optic Illuminator

List Price: $820.00

Our Price: $789.00

$ 789.00

SKU: FT192

Availability: In stock

  • Powerful 21V/150 watt Quartz Halogen
  • Power Supply: 120V 50/60 Hz
  • Variable Controlled Lighting - 50% to 100%
  • Lamp Color Temperature: 3200 K
  • Annular Light Guide with 60mm dia. Light Ring

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • FT192
Description

Summary

This Meiji professional fiber-optic illuminator provides 150W of powerful halogen illumination and fits all RZ and EMZ stereo microscopes; adapter required for EMT and EMF stereos. Ideal for both industrial and laboratory applications requiring fiber-optic illumination.

Illuminator

The quartz halogen light source allows a continuous range of subdued or concentrated lighting, controlled by a rotary dimmer dial on the front panel. The lamp color temperature is 3200ºK providing 40,000 foot candles of cold illumination, while forced-air cooling ensures a long lamp service life.

Annular Flexible Light Guide

The Annular light guide features a 36" flexible cable with 10mm dia. fiber optic bundle and a 60mm diameter ring aperture designed to fit RZ and EMZ stereo microscopes. EMF series microscopes will need adapter MA553, and EMT series will need adapter MA553/05. UL-1571 and CE/CSA 2001 compliant.

  • Fuse: 2 A
  • Weight: 8 LB
  • Package Dimensions: 38x26x21cm
0 0
Specifications

FT192 150W Annular Fiber Optic Illuminator
General
Brand Meiji Techno
SKU FT192
Short Description
  • Powerful 21V/150 watt Quartz Halogen
  • Power Supply: 120V 50/60 Hz
  • Variable Controlled Lighting - 50% to 100%
  • Lamp Color Temperature: 3200 K
  • Annular Light Guide with 60mm dia. Light Ring
Notes
Feed - Title Meiji Techno FT192 150W Annular Fiber Optic Illuminator
Feed - Description The Meiji SMT-8TR stereo microscope inspection station is designed specifically for close inspection of soldering welds on circuit boards and delicate electronics repairs. It combines Meiji's best-selling EMZ-8TR zoom stereo trinocular microscope body, the S-4100 boom inspection stand, FT192 fiber op t ic annular ring illumination system and two sets (10X and 20X) of wide field eyepieces. Limited Lifetime Warranty.MicroscopeThe EMZ-8TR stereo trinocular head is one of Meiji's most popular stereo microscope heads. It is their workhorse industrial and educational head offering good quality, an affordable price and zero defects. The parfocal zoom range is 7x-45x with dual-sided zoom controls and provides a field of view of 32mm-5.1mm. The working distance is 104mm. The head is inclined 45
Feed - Custom Label 1 500-1000
Compatibility
Compatible With FL151, FL152
Light Specs
Illumination Type Halogen, Fiberoptic
Bulb Accessory
Bulb Wattage 150W
