PLS-1 Pole Stand
SKU:
PLS1
In stock
You pay:
$725.00
Free Shipping,
30 Day Money Back Guarantee
- Solid pole stand
- Integrated 5W LED incident illumination
- Black and white stage plate with stainless steel clips
- Rack and pinion movement with safety clutch
- Lifetime Limited Warranty
The PLS-1 is a versatile and effective 20mm diameter pole stand which includes an F-series focus block and plain base. The focusing block has integrated 5W, variable-intensity LED incident illumination and dual coarse focus knobs. The focus block comes with rack and pinion gearing, a safety clutch with tension adjustment and 55mm of travel. Twin mounting clips position and secure specimens on a 94.5mm reversible black and white stage plate.
Total Height: 251mm (9.88”), Pillar only: 212.85 mm (8.38”) Base dimensions: 180mm (7.08”) wide x 272mm (10.70”) (For use with all EM stereo bodies)
| Brand | Meiji Techno |
|---|---|
| Recommended For | 0 |
| Stand Class | Pedestal |
| Stand Type | Pole |
| Stage Plate | Black/White Contrast Plate |
| Post Diameter | 20 mm |
| Requires Separate Hanging Bar? | No |
| Focus Block Mount Diameter | 20 mm |
| Focus Controls | Coarse |
| Focus Mechanism | Rack & Pinion |
| Head Ring Mount Diameter | 84 mm |
