Omano OM118-B4L 40X-1000X LED Compound Student Microscope Gift Package

$ 248.00

List Price: $517.00

Starting at: $248.00

SKU: OM118B4L-XSP

Availability: In stock

  • THE PERFECT GIFT
  • SAVE more with choice of 4 accessory packs
  • Most affordable binocular microscope with slide holder
  • 4 Magnification levels: up to 1,000x
  • Mechanical slide holder for ease of use
  • Coaxial coarse/fine focus for easy adjustment
  • Professional Abbe 1.25 NA condenser
  • Bright LED illumination
  • Recommended for Grades 4-12

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

OM118-B4L Compound LED Microscope   $239.00
  • $59.00
  • $88.00
  • $139.00
  • $209.00
  • $239.00

Included in Bundle

Microscope: OM118-B4L Compound LED Microscope

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • OM118-B4L LED Compound Student Microscope Gift Package
  • OM118-B4L LED Compound Student Microscope Gift Package 1
  • OM118-B4L LED Compound Student Microscope Gift Package 2
  • OM118-B4L LED Compound Student Microscope Gift Package 4
  • OM118-B4L LED Compound Student Microscope Gift Package 5
  • OM118-B4L LED Compound Student Microscope Gift Package 5
Description

THE PERFECT GIFT

Summary

This year, treat the young scientist in your family to the Omano OM118-B4 microscope with a choice of 4 useful Accessory gift packs. Part of the affordable OM118 series, the OM118-B4 is a binocular compound microscope that includes four objective lenses and a mechanical slide holder for convenient slide handling on the microscope stage. Four levels of magnification, 40x, 100x, 400x and 1,000x are derived from two WF10x eyepieces and 4x, 10x, 40xS and 100xS oil immersion, objectives. Like the monocular sister microscopes (OM118-M3 and M4), this binocular version was introduced in 2010 as an economical alternative to our ever popular Omano OM36B and OM36 series. The microscope includes a 5-year Omano limited warranty.

Optics

The Omano OM118-B4 includes a binocular microscope head that is inclined at an ergonomic 45 degrees. The head rotates through 360 degrees for flexible viewing positions. There are two Wide Field WF10x eyepieces that combine with four parcentered, parfocal achromatic objectives lenses, (4x, 40x spring, 100x spring oil immersion) for magnification levels of 40x, 100x, 400x and 1,000x. The objectives are set in a quadruple nosepiece. The oculars both have diopters that enable individual eye focusing while the head can be adjusted through 55-75mm to adapt for different interpupillary distances.

Stage & Focus

The microscope includes a plain stage with mechanical slide holder that enables easy slide movements on the stage. The slide holder is an improvement over a plain stage since it allows for more convenient slide handling, but it is not as ergonomic as a full mechanical stage found on the OM118-B4S. Focusing includes rack and pinion design for durability and coaxial coarse and fine focus controls. We recommend coaxial coarse/fine focus controls since they enable 'eyes down' focusing. In other words, the viewer does not constantly need to look up in order to find the other focus control.

This benefit is important in enhancing a student's experience and therefore in encouraging a more sustained interest in the microscope. Safety features include a rack stop to ensure that the stage does not impact with the objectives and thereby break the slides and a slip clutch control to mitigate the risk of damaging the focus controls through over extension.

Condenser & Illumination

The condenser is Abbe 1.25 N. A with iris diaphragm for optimal adjustments. Transmitted long-life LED illumination includes variable intensity and is rated for 110V/120V.

Accessories

Eyecups, Dust Cover, Manual, Spare Bulb, Spare Fuse, Immersion oil

Shipping Wt. and dimensions: 12 Lb. 20"x13"x10".

Accessory Packs

In addition to the regularly included accessories, you can choose from 4 accessory packs below. Each pack includes a range of useful accessories that you will need in order to enjoy your microscope.

Pack 1: Book + 5 Prepared Slides

Book: Usborne's, The World of the Microscope
The book is, in our opinion, a wonderful and colorful introduction to microscopy. Practical, clearly worded and with dozens of illustrations, it provides numerous experiments and activities that range from simple to more complex. While many assume the book is aimed at children, we have found it to be an useful primer for both young and old alike. We highly recommend it.

5 Prepared Slides:
Inspired by a permanent exhibition at The Natural History Museum in London, the Beastly Bits range includes three different sets of five slides:  Beastly Bits (Animal), Blood & Gore (Human tissue) or Neat Eats (Vegetable). All are professional-grade, prepared slides designed to stimulate the imagination of children - and adults alike! Beastly Bits set will be included unless sold out, when either Blood & Gore or Neat Eats will be substituted.


Pack 2: Book + Slide and Stain Kit

Book: Usborne's, The World of the Microscope

Slide and Stain Kit:
Perfect for individual, laboratory, home school or classroom use. Eosin Y is especially helpful in bone and marrow testing, while Methylene Blue is an excellent test for DNA. Kit includes the following items:

 - Eosin Y stain, 1%, 15 ml
 - Methylene Blue Stain, 1%, 15 ml
 - 1 oz Lens Cleaning Fluid
 - 50 Premium Blank Slides
 - 100 Slide Covers - 22mm x 22mm
 - 3 Well Slides
 - Dropper or Pipette
 - Lens Cleaning paper
 - BS Plastic slide storage case
 - Instructions booklet.
5 Prepared Slides:


Pack 3: Book + Slide Kit + 15 Prepared Slides

Book: Usborne's, The World of the Microscope

Slide Kit
This Compound Microscope Starter Slide Kit is our most popular accessory and contains the following essential items:

 - 50 Blank Slides
 - 100 Cover slips
 - 3 Well Slides
 - Dropper and Lens Cloth

15 Prepared Slides:
This microscope slide kit contains a mix of 15 prepared slides in a durable plastic case. The selection of specimens are stained and carefully mounted on glass slides with cover slips. Each slide is labeled and conveniently arranged in the plastic case. v



Microbiology Kit with Book

This student microbiology experimentation and study kit has everything you need to grow your own bacteria cultures. Experiment with bacteria in the air, on your hands and more with help from the included, "World of the Microscope" book, a wonderful student guide to microscopy. Your microbiology kit also includes 5 professionally prepared slides inspired by a permanent exhibition at The Natural History Museum in London to fire the imagination of children - and adults alike.

Microbiology Kit includes the following items:

  • 5 Prepared Slides
  • 50 Premium Blank Slides
  • 100 Slide Covers - 22mm x 22mm
  • 1 Dropper or Pipette
  • 6 Swabs
  • 3 Well Slides
  • 3 Petri dishes
  • 5 gm Nutrient Agar
  • Gloves

Omano OM118 Series

Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • OM118-B4L Compound LED Microscope
    General
    Brand Omano
    SKU OM118-B4L
    Warranty 5 Year Warranty
    Notes We introduced this microscope as a cheaper alternative to our ever-popular Omano OM36 binocular compound microscope. It is not as solidly built as the OM36 but does offer a microscopy soltuion to those on a more limited budget. See the OM-118-b4S for a fuller featured version of this microscope.
    System
    System Type Brightfield
    Optical Design DIN 160mm
    Head
    Head Type Binocular
    Ocular Angle 45°
    Interpupillary Adjustment Linear Sliding
    Interpupillary Adjustment Range 55-75 mm
    Ocular Tube Diameter 23 mm
    Body
    Nosepiece Orientation Front-facing
    Nosepiece Style Quadruple (4)
    Focus Controls Coarse & Fine, Coaxial
    Focus Mechanism Rack & Pinion
    Focus Control Location Dual Ambidextrous
    Stage Type Fixed with Attached Mechanical Slide Holder
    Stage Features Slide Holder (spring-loaded)
    Configuration
    Includes Eyepieces? Yes
    Included Eyepiece Quantity 2
    Included Eyepieces (X) 10X
    Eyepiece Style WF Widefield (FN 18mm)
    Min Standard Mag 40X
    Max Standard Mag 1000X
    Included Objectives (Qty) 4
    Objective Lens Achromatic
    Included Objective Types Brightfield
    Condenser
    Condenser Type Abbe Brightfield
    Condenser Features Iris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder
    Condenser N.A. 1.25 mm
    Illumination
    Illumination Type LED
    Illumination Style Transmitted
    Collector Type Simple
    Transmitted Light Type Halogen
    Transmitted Light Specification 6V 20W
    Transmitted Light Control Variable
    Power Supply 110V Only
    Accessories
    Included Extras Spare Bulb, Spare Fuse, Dust Cover

  • Pack 1: Book & 5 Prepared Slides

    Pack 2: Book, Starter Slide & Stain Kit & 5 Prepared Slides

    Pack 3: Book, Starter Slide Kit & 15 Prepared Mixed Slides

    Microbiology Kit with Starter Slide Kit & Book

    Amazing Microscope Adventure Cards - Activities and Experiments for Kid's 8+
    General
    Brand OmanoOmanoOmanoOmanoOmano
    SKU PACK-1PACK-2PACK-3MOMSK-MICROOMA-EXP-1
    Notes  $13.50 cost
    Product Weight 1.00001.00001.00001.0000
    Feed - Title  Omano Microbiology Kit with Starter Slide Kit & BookFinger Print Education Kit
    Feed - Description  THE PERFECT GIFT This year, treat the young scientist in your family to the Omano OM118-B4SL LED microscope with a choice of 4 useful Accessory gift packs. Part of the affordable OM118 series, the OM118-B4S is a binocular compound microscope that includes four objective lenses and a full floating stage for convenient slide handling on the microscope stage. Four levels of magnification, 40x, 100x, 400x and 1,000x are derived from two WF10x eyepieces and 4x, 10x, 40xS and 100xS oil immersion, objectives. Like the monocular sister microscopes (OM118-M3 and M4), this binocular version was introduced in 2010 as a more affordable alternative to our ever popular Omano OM36 series. It has similar optics to the OM36C, and features a rugged, all-metal design and construction.The microscope includes a 5-year Omano limited warranty.OpticsThe Omano OM118-B4SL includes a binocular microscope head that is inclined at an ergonomic 45 degrees. The head rotates through 360 degrees for flexible viewing positions. There are two Wide Field WF10x eyepieces that combine with four parcentered, parfocal achromatic objectives lenses, (4x, 40x spring, 100x spring oil immersion) for magnification levels of 40x, 100x, 400x and 1,000x. The objectives are set in a quadruple nosepiece. The oculars both have diopters that enable individual eye focusing while the head can be adjusted through 55-75mm to adapt for different interpupillary distances.Stage & FocusThe primary difference between this microscope and the Omano OM118-B4 is in the stage. This microscope includes an integrated, double-layered mechanical stage as opposed to a detachable mechanical slide holder on the OM118-B4. In the final analysis, an integrated mechanical stage is the only answer for any serious student or professional microscopist. While a mechanical slide holder is an improvement on a plain stage, a mechanical stage includes full graduated X/Y movement (18mm x 70mm) with coaxial coarse/fine focus controls. Such coaxial controls enable a student to move the slide without looking up from the eyepiece; for regular users this benefit is an indispensable convenience. Focusing includes high quality rack and pinion mechanics for longer life and coaxial focus controls for easier focusing. We recommend coaxial coarse/fine focus controls since they enable 'eyes down' focusing. In other words, the viewer does not constantly need to look up in order to find the other focus control. This benefit is important in enhancing a student's experience and therefore in encouraging a more sustained interest in the microscope. Safety features include a rack stop to ensure that the stage does not impact with the objectives and thereby break the slides and a slip clutch control to mitigate the risk of damaging the focus controls through over extension.Condenser & IlluminationThe condenser is Abbe 1.25 N. A with iris diaphragm for optimal adjustments. Transmitted LED illumination includes variable intensity and is rated for 110V/120V. Wt. and dimensions: 12 Lb. 20"x13"x10".AccessoriesEyecups, Dust Cover, Manual, Spare Bulb, Spare Fuse, Immersion oil.Free Gift - 20X Jewelers Loupe Rocks, bugs, sea shells and antique coins are no longer safe, with this 20X Loupe in the hands of a young explorer. Also handy for hobby work and discovering the intricacy of a small flower or butterfly wing, picking out a sliver, admiring miniature art, viewing photography or helping Mom or Dad read the "fine print" of a document. Accessory PacksIn addition to the regularly included accessories, you can choose from 4 accessory packs below. Each pack includes a range of useful accessories that you will need in order to enjoy your microscope. Pack 1: Book + 5 Prepared Slides Book: Usborne's, The World of the MicroscopeThe book is, in our opinion, a wonderful and colorful introduction to microscopy. Practical, clearly worded and with dozens of illustrations, it provides numerous experiments and activities that range from simple to more complex. While many assume the book is aimed at children, we have found it to be an useful primer for both young and old alike. We highly recommend it. 5 Prepared Slides:Inspired by a permanent exhibition at The Natural History Museum in London, the Beastly Bits range includes three different sets of five slides:The new Omano OM-123L LED is a rechargeable LED stereo microscope with three levels of magnification: 10x, 20x and 30x. All metal with high quality glass optics, it can be used either indoors or outside in the field. It offers exceptional value for first time users or home hobyists and is used to view macro specimens that are visible to the naked eye such as insects, crystals, sea shells and more. The microscope includes 10x/20x/30x triple power magnification with WF10x eyepieces.It also features top and bottom, variable intensity LED illumination which is rechargeable and lasts all day on a single charge. Combined with a tough, ergonomic handle, this microscope is highly portable and convenient for use in the field or classroom with no need for messy wires. OpticsTwo Wide Field WF10x eyepieces combine with 1x/2x/3x objectives in a step turret magnification changer for magnification powers of 10x, 20x and 30x. Simply twist the objective housing until it clicks into place on the desired objective.The microscope also includes rubber eyeguards for improved viewing, adjustable interpupillary distance of 55-77mm and a left eyepiece diopter to allow for individual eye focusing. Focus & IlluminationAs with most stereo microscopes, the OM123L includes dual-sided coarse focus controls with over-sized knobs which are easier for student hands to use. Top and bottom illumination is powered by 110V ac or rechargeable LED with three settings: top, bottom and top and bottom together.StandThe OM123L includes a pedestal stand with included top and bottom LED illumination controllable with left and right side dimmer switches. Easy-to-use, affordable and no need for power cords to trip up the young ones, it is a perennial favorite!AccessoriesAccessories include rubber eyecups, a reversible black/white stage plate, frosted glass stage plate, two metal stage clips, vinyl dust cover and manual. Wt. and dimensions: 12 Lb. 16" x 14" x 10".
    Feed - Custom Label 1  <100<100

  • Summit KK2-1.3 1.3MP Windows-Only Color Digital Camera

    Summit SK2-1.3X 1.3MP PC / MAC Compatible Digital Microscope Camera

    Summit SK2-3.1X 3.1MP PC / MAC Compatible Digital Microscope Camera

    Summit SK2-5.2X 5.0MP PC / MAC Compatible Digital Microscope Camera

    Summit SK2-10X 10.0MP PC / MAC Compatible Digital Microscope Camera
    General
    Brand OptixCamOptixCamOptixCamOptixCamOptixCam
    SKU OCS-KK2-1.3OCS-SK2-1.3XOCS-SK2-3.1XOCS-SK2-5.2XOCS-SK2-10X
    Warranty 1 Year1 Year1 Year1 Year1 Year
    Product Weight 2.00002.00002.00002.00002.0000
    Product Display
    New Yes
    Sensor
    Sensor Type CMOSCMOSCMOSCMOSCMOS
    Sensor Size 1/3 Inch1/3 Inch1/2 Inch1/3 Inch1/3 Inch
    Sensor Details  Aptina MT9M111 CMOSAptina MT9T001 CMOSAptina MT9P001 CMOSAPTINA MT9J003 CMOS
    Color/Monochrome ColorColorColorColorColor
    Pixel Pitch 3.6 µm x 3.6 µm3.6 µm x 3.6 µm3.2 µm x 3.2 µm2.2 µm x 2.2 µm1.7 µm x 1.7 µm
    Sensor Color Depth 8bpp / 24bit RGB8bpp / 24bit RGB8bpp / 24bit RGB8bpp / 24bit RGB8bpp / 24bit RGB
    Scan Mode ProgressiveProgressiveProgressiveProgressiveProgressive
    Signal to Noise Ratio  44 db43 db40.5 db34 db
    Sensitivity  1.0V/Lux-sec (550nm)1.0V/Lux-sec (550nm)1.0V/Lux-sec (550nm)1.0V/Lux-sec (550nm)
    Dynamic Range  71 db61db66.5db65.2db
    A/D Conversion  10-bit Parallel, 8-bit RGB to PC12-bit Parallel, 8-bit RGB to PC12-bit Parallel, 8-bit RGB to PC12-bit Parallel, 8-bit R.G.B to PC
    Cooling System  NaturalNatural
    Shutter Electronic, Rolling ShutterElectronic, Rolling ShutterElectronic, Rolling ShutterElectronic, Rolling ShutterElectronic, Rolling Shutter
    Camera
    Camera Mount Ocular MountC-Mount, Ocular MountC-Mount, Ocular MountC-Mount, Ocular MountC-Mount, Ocular Mount
    Resolution 1.3 Megapixel, 1280x1024 pixels1.3 Megapixel, 1280x1024 pixels3 Megapixel, 2048x1536 pixels5 Megapixel, 2592 X 1944 pixels10 Megapixel, 3584 X 2748 pixels
    Camera Output Resolutions 1280 X 1024; 640 X 512; 320 X 2561280 X 1024; 640 X 512; 320 X 2562048 x 1536; 1024 x 768; 680 x 5102592 X 1944; 1280 X 960; 640 X 4803584 X 2748; 1792 x 1374; 896 X 684
    FPS @ Max Res 7.5fps @ 1280 x 102415@1280x1024; 26@640x512; 48@320x25611.5@2048x1536; 32@1024x768; 45@680x5105fps @ 2592 X 19441.9fps @3584 x 2748
    FPS @ Min Res 12.5fps @ 800 x 60050fps @ 320 x 25643fps @ 680 x 51060fps @ 640 X 48027fps @896 x 684
    Camera Interface USB 2.0USB 2.0USB 2.0USB 2.0USB 2.0
    White Balance Automatic, ManualAutomatic, ManualAutomatic, ManualAutomatic, ManualAutomatic, Manual
    Software Included OptixCam K2ViewOptixCam K2ViewOptixCam K2ViewOptixCam K2ViewOptixCam K2View
    Driver API Compatibility DirectX, TWAINDirectX, TWAINDirectX, TWAINDirectX, TWAINDirectX, TWAIN
    Power Source USB PoweredUSB PoweredUSB PoweredUSB PoweredUSB Powered
    File Formats JPEGBMP, JPEG, Own Proprietary, PNG, TGA, TIFFBMP, JPEG, Own Proprietary, PNG, TGA, TIFFBMP, JPEG, Own Proprietary, PNG, TGA, TIFFBMP, JPEG, Own Proprietary, PNG, TGA, TIFF
    Exposure Control Automatic, ManualAutomatic, ManualAutomatic, ManualAutomatic, ManualAutomatic, Manual
    Exposure Time 2000ms-0.14Ms2000ms-0.14Ms2000ms-0.128s2000ms-0.21s2000ms-0.21s
    Operating Temperatures 10°C ~ 50°C10°C ~ 50°C10°C ~ 50°C10°C ~ 50°C10°C ~ 50°C
    Operating Humidity 30% ~ 80% RH30% ~ 80% RH30% ~ 80% RH30% ~ 80% RH30% ~ 80% RH
    Storage Temperature -20°C ~ 60°C-20°C ~ 60°C-20°C ~ 60°C-20°C ~ 60°C-20°C ~ 60°C
    Other Details
    Included Accessories 0.5X 23mm Ocular adapter, Software CD0.5X 23mm DIN Adapter, Software CD0.5X 23mm DIN Adapter, Software CD0.5X 23mm DIN Adapter, Software CD0.5X 23mm DIN Adapter, Software CD
    Supported Operating Systems Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+, Linux (kernel 2.6.26+)Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+
    System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
    Certifications CE, ULCE, ULCE, ULCE, ULCE, UL
    Cable Length 1.8m (8ft)1.8m (8ft)1.8m (8ft)1.8m (8ft)1.8m (8ft)
    Camera Warranty 1 Year1 Year1 Year1 Year1 Year
    Software Support 6 Months6 Months6 Months6 Months6 Months
    Compatibility
    Imaging Compatibility (with adapters) 23mm 23mm , C-Mount23mm , C-Mount23mm , C-Mount23mm , C-Mount
