Omano OMSHOP Compact Shop Microscope - 100X

List Price: $129.00

Our Price: $99.00

SKU: OMSHOP-10X

Availability: In stock

  • Included 10X objective
  • Cross-linear reticle
  • Rack & Pinion focus with dual knobs and lock
  • LED penlight
  • Industrial quality

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Omano OMSH1 Compact Shop Microscope
Description

This compact handheld inspection microscope is ideal for handheld shop inspection tasks and the solid metal unit will provide years of dependable service.

Available with a range of optional objectives (2X, 4X, 10X) to suit specific applications. The 10X objective combined with the standard 10X eyepiece, results in 100X magnification. Includes locking ring to allow quick return to ideal focal range.

Lighting is provided by a removable battery-powered pen light LED illuminator on a swivel mount.  Supplied in padded storage box.

Shipping Wt. and dimensions: 3 Lb. 10"x8"x6".

Specifications

OMSHOP Compact Shop Microscope - 100X
General
SKU OMSHOP-10X
Short Description
  • Included 10X objective
  • Cross-linear reticle
  • Rack & Pinion focus with dual knobs and lock
  • LED penlight
  • Industrial quality
Warranty Limited Lifetime Warranty
System
System Type Brightfield
Optical Design DIN 160mm
Head
Head Type Monocular
Ocular Angle Vertical
Ocular Tube Diameter 23 mm
Body
Nosepiece Style Single (1)
Focus Controls Coarse
Focus Mechanism Rack & Pinion
Focus Control Location Dual Ambidextrous
Configuration
Includes Eyepieces? Yes
Included Eyepiece Quantity 1
Included Eyepieces (X) 10X
Eyepiece Style WF Widefield (FN 18mm)
Min Standard Mag 100X
Max Standard Mag 100X
Min Configured Mag 20X
Max Configured Mag 100X
Objectives
Included Objectives (Qty) 1
Objective Lens Achromatic
Included Objective Types Brightfield
Objective 1 Description 10X
Illumination
Illumination Type LED
Illumination Style Incident
Incident Light Type LED
Incident Light Control On/Off
Power Supply 1 AAA Battery
Accessories
Case Included? Yes
