Meiji Techno EMF-1 Fixed 1X Mag Stereo Binocular Head

$ 510.00

List Price: $620.00

Starting at: $510.00

SKU: EMF-1

Availability: In stock

  • Meiji's most popular fixed stereo microscope head
  • 108mm working distance
  • Rotatable through 360°
  • Binocular format
  • MA502 10X Eyepieces are included
  • Lifetime Limited Warranty
  • Shown with optional eyeshields

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

EMF-1 Fixed 1X Mag Stereo Binocular Head   $360.00
MA502 - 10X Super Widefield Paired Eyepieces   $150.00
  • $10.00

Included in Bundle

Type of Head: EMF-1 Fixed 1X Mag Stereo Binocular Head

Eyepieces: MA502 - 10X Super Widefield Paired Eyepieces

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

Description

The EMF-1 stereo head is an economical yet quality Meiji product, offering 10x magnification and eyetubes inclined 45 degrees. The eye tubes also rotate 360-degrees and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 108mm. Higher magnification is available with optional eyepieces and objectives.

MA502 10X Eyepieces are included with the head.

Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • EMF-1 Fixed 1X Mag Stereo Binocular Head
    General
    Brand Meiji Techno
    SKU EMF1
    Head
    Head Type Binocular
    Optical Design Greenough Converged
    Magnification Type Fixed
    Ocular Angle 45°
    Ocular Tube Diameter 30.5 mm
    Diopter Adjustment Single
    Interpupillary Adjustment Arc (Seidentopf)
    Interpupillary Adjustment Range 54mm - 75mm
    Head Rotation 360 Degrees
    Minimum Objective (X) 1
    Maximum Objective (X) 1
    Body
    Body Material All-Metal
    Head Ring Mount Diameter 84 mm
    Max Working Distance (standard) 108 mm

  • MA502 - 10X Super Widefield Paired Eyepieces
    General
    Brand Meiji Techno
    SKU MA502
    Warranty Meiji Limited Lifetime Warranty
    Notes 30.5mm OD, 25mm reticle mount, Fits MEIJI EM SERIES ONLY
    Feed - Title Meiji Techno MA502 - 10X Super Widefield Paired Eyepieces
    Feed - Description The Meiji SMD-5 stereo microscope inspection station is designed specifically for close inspection of soldering welds on circuit boards and delicate electronics repairs. It combines Meiji's best-selling EMZ-5 zoom stereo binocular microscope body, the S-4100 boom inspection stand, MA964 LED ring illumination system and two sets (10X and 20X) of wide field eyepieces. Limited Lifetime Warranty.MicroscopeThe EMZ-5 stereo binocular head is one of Meiji's most popular stereo microscope heads. It is their workhorse industrial and educational head offering good quality, an affordable price and zero defects. The parfocal zoom range is 7x-45x with dual-sided zoom controls and provides a field of view of 32mm-5.1mm. The working distance is 93mm. The head is inclined 45
    Feed - Custom Label 1 100-500
    Compatible With EM*
    Eyepiece Magnification 10x

  • MA600 Stereo Eyeshields (Pair)
    General
    Brand Meiji Techno
    SKU MA600
    Feed - Title Meiji Techno MA600 Stereo Eyeshields (Pair)
    Feed - Description The Meiji SMD-5 stereo microscope inspection station is designed specifically for close inspection of soldering welds on circuit boards and delicate electronics repairs. It combines Meiji's best-selling EMZ-5 zoom stereo binocular microscope body, the S-4100 boom inspection stand, MA964 LED ring illumination system and two sets (10X and 20X) of wide field eyepieces. Limited Lifetime Warranty.MicroscopeThe EMZ-5 stereo binocular head is one of Meiji's most popular stereo microscope heads. It is their workhorse industrial and educational head offering good quality, an affordable price and zero defects. The parfocal zoom range is 7x-45x with dual-sided zoom controls and provides a field of view of 32mm-5.1mm. The working distance is 93mm. The head is inclined 45
    Feed - Custom Label 1 <100
