Motic PSM-1000 Trinocular Microscope, Head Only
- Superior Optical Performance: Engineered as a high-performance OEM component specifically for imaging flat, reflective specimens in metallurgy and semiconductor inspection.
- Exceptional Resolution: Compatible with optional Extra Long Working Distance (ELWD) Plan Apochromatic objectives, delivering professional-grade resolving power and clarity.
- Expansive Field of View: Features a large FOV24, allowing for a broader perspective of the sample area to increase throughput.
- True Image Orientation: Provides an erect, true-sided image to ensure intuitive orientation and effortless manipulation of delicate components.
- Modular Industrial Design: Optimized for seamless integration into industrial machinery, probe stations, and custom inspection systems.
Motic PSM-1000: The Industry Standard for Laser Integration & Repair
The PSM-1000 Laser-Ready Modular Microscope is a high-performance research platform engineered specifically for the semiconductor, micro-repair, and laser-processing industries. Designed to handle the most demanding laser applications, this system provides a seamless transition between observation and laser work without compromising optical integrity or user comfort.
Engineered for Precision Laser Work
The PSM-1000 comes standard-equipped to handle laser spectrums ranging from 355nm (UV) to 532nm (Green) and up to 1064nm (IR). Its specialized lens design ensures maximum transmission and safety across the Near-UV to Near-IR spectrum, making it the premier choice for circuit editing and wafer substrate inspection.
- High-Capacity Focusing Block: Built to withstand heavy industrial use, the focusing mechanism is rated for loads up to 45 lbs. with a 1μm fine focus resolution.
- 3-Lens Change-over Turret: Switch effortlessly between 1X UV/VIS, 1X IR/VIS, and 2X magnification for rapid inspection.
- Adjustable Nosepiece: The quadruple, forward-facing nosepiece features single centerable positions and uses M26 x 0.706 mounting threads for industry-standard objectives.
- Ergonomic Versatility: Available with standard 30° inclined heads or specialized 3°-30° tilting heads (PSM-1000E) to accommodate various user heights and workstation setups.
Model Comparison & Technical Specifications
| Feature | PSM-1000 (Standard) | PSM-1000E (Ergo) |
|---|---|---|
| Observation Tube | Trinocular Siedentopf (30° Inclination) | Trinocular Tilting (3°-30° Range) |
| Optical Spectrum | NUV (355nm) to Visible to NIR (1064nm) | |
| Trinocular Light Split | 50:50 / 0:100 (Observation/Photo) | |
| Eyepieces | Widefield WF10X/24mm with +/- 5 Diopter Adjustment | |
| Focusing Stroke | 50mm Total Travel (1μm increments on standard systems) | |
| Nosepiece | Quadruple, Dovetail Mounted, Centerable Positions | |
| Illumination Port | Fiber-optic Coaxial Port for Incident Lighting | |
Safety First: Integrated Laser Protection
Every PSM-1000 system is supplied with a Laser Safety Kit, including a laser safety pin and specialized shims to ensure the optical path is secure during high-energy laser firing. This makes it an ideal platform for OEM integration and laboratory research.
Build Your Modular System
From Extra Long Working Distance (ELWD) Plan Apochromatic objectives to polarization sliders, the PSM-1000 is fully customizable.
| Brand | Motic |
|---|---|
| Recommended For | 0 |
| Trinocular Tube Focusable? | No |
| Parfocal | No |
| Focus Controls Graduated? | No |
| Stage Range Graduated? | No |
| Includes Eyepieces? | No |
| Includes Eyecups? | No |
| Included Objectives Parfocal Adjustable? | No |
| Reticles Available? | No |
| Case Included? | No |
