OptixCam Summit SK2-1.3X 1.3MP PC/MAC Digital Microscope Camera

$ 88.00

List Price: $175.00

Starting at: $88.00

SKU: TMS-SK2-1.3X

Availability: In stock

  • 1.3 MP with excellent color resolution
  • Stills & Live Image video
  • PC/MAC Compatible
  • 0.37X reducing lens for improved field of view
  • Integrated C-mount to fit most microscopes
  • MAC limited to image capture only
  • FREE telephone support

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

Summit SK2-1.3X 1.3MP PC / MAC Compatible Digital Microscope Camera   $88.00
  • $59.00
  • $25.00
  • $5.00

Included in Bundle

Camera: Summit SK2-1.3X 1.3MP PC / MAC Compatible Digital Microscope Camera

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Summit SK2-1.3X 1.3MP PC/Mac Compatible Digital Microscope Camera
  • Summit SK2-1.3X 1.3MP PC/Mac Compatible Digital Microscope Camera
  • Summit SK2-5.2X 5.0MP PC/Mac Compatible Digital Microscope Camera sensor
  • Summit SK2-1.3X 1.3MP PC/Mac Compatible Digital Microscope Camera mounted
  • Summit SK2-1.3X 1.3MP PC/Mac Compatible Digital Microscope Camera with microscope
Description

Summary
The OptixCam Summit Series SK2-1.3x USB digital microscope camera is recommended for most general microscopy documentation applications. It is widely used in industrial inspection, schools and at home for both live video and stills. The camera features accurate color resolution, optimal image quality and a rugged aluminum housing for protection.  Characterized by fast refresh rates up to fps, auto/manual exposure, time.



Software
 Included image capture and measuring software is easy-to-use with helpful features such as auto white balance, color enhancement, anti-flicker, notation, geometric measuring and multiple file format storage. The camera includes a 0.5x 23mm adapter that ensures images closer to those seen through the eyepieces. Designed for PCs, it is also Mac compatible for image capture only. TWAIN, DirectX compatible.


Camera Features

  • 1.3MP resolution
  • Accurate color reproduction
  • Full PC compatibility, Mac (image capture)
  • Fast refresh rates – 50fps max
  • Comparable FOV to eyepieces
  • Multiple file formats – Jpeg, BMP, PNG, TIFF, TGA
  • Included 0.5x 23mm Adapter for C-Mount
  • Included image capture & measuring software
  • Rugged aluminum housing
  • Accessories: USB cable, software CD, 0.5x 23mm adapter

Software Features

  • Plug-n-play
  • Live imaging video
  • Manual/Auto focus
  • Auto white balance
  • Time lapse
  • Anti-Flicker
  • Notation
  • Geometric measuring – line, circles, angles etc
  • Accessories: Software CD,  23.2mm Eyepiece adapter, US2.0 cable.
  • Dimensions: 58mm x 58mm x 32mm
  • Weight: 1.2 lb.



SK2 Digital Camera Installation Video

Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • Summit SK2-1.3X 1.3MP PC / MAC Compatible Digital Microscope Camera
    General
    Brand OptixCam
    SKU OCS-SK2-1.3X
    Warranty 1 Year
    Product Weight 2.0000
    Sensor
    Sensor Type CMOS
    Sensor Size 1/3 Inch
    Sensor Details Aptina MT9M111 CMOS
    Color/Monochrome Color
    Pixel Pitch 3.6 µm x 3.6 µm
    Sensor Color Depth 8bpp / 24bit RGB
    Scan Mode Progressive
    Signal to Noise Ratio 44 db
    Sensitivity 1.0V/Lux-sec (550nm)
    Dynamic Range 71 db
    A/D Conversion 10-bit Parallel, 8-bit RGB to PC
    Shutter Electronic, Rolling Shutter
    Camera
    Camera Mount C-Mount, Ocular Mount
    Resolution 1.3 Megapixel, 1280x1024 pixels
    Camera Output Resolutions 1280 X 1024; 640 X 512; 320 X 256
    FPS @ Max Res 15@1280x1024; 26@640x512; 48@320x256
    FPS @ Min Res 50fps @ 320 x 256
    Camera Interface USB 2.0
    White Balance Automatic, Manual
    Software Included OptixCam K2View
    Driver API Compatibility DirectX, TWAIN
    Power Source USB Powered
    File Formats BMP, JPEG, Own Proprietary, PNG, TGA, TIFF
    Exposure Control Automatic, Manual
    Exposure Time 2000ms-0.14Ms
    Operating Temperatures 10°C ~ 50°C
    Operating Humidity 30% ~ 80% RH
    Storage Temperature -20°C ~ 60°C
    Other Details
    Included Accessories 0.5X 23mm DIN Adapter, Software CD
    Supported Operating Systems Windows 10, Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+
    System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
    Certifications CE, UL
    Cable Length 1.8m (8ft)
    Camera Warranty 1 Year
    Software Support 6 Months
    Compatibility
    Imaging Compatibility (with adapters) 23mm , C-Mount

  • Adjustable 23mm Camera Adapter 0.37X for SK2 Series Cameras
    General
    Brand OptixCam
    SKU OCS-SK2-CA037X-23MMA
    Warranty Omano Limited Lifetime Warranty
    Backorder ETA Nov 30, 2018
    Feed - Title OptixCam Adjustable 23mm Camera Adapter 0.37X for SK2 Series Cameras
    Feed - Description The new Optixcam OCS-SK2-HDMI-7 high-definition CMOS color microscopy camera is a professionally-designed, stand-alone imaging solution offering sharp, 1280 x 720 resolution images or video @ 30Fps in a cost-effective package. The camera offers direct streaming to an HDMI monitor without the complexity of computer software, making it an ideal imaging solution for fast-paced industrial environments and technical training classrooms.FeaturesHDMI (High-Definition Multimedia Interface) technology brings a number of key benefits to digital microscopy, including richer color definition, better signal integrity, greater bandwidth capacity, encryption protocols and high-definition video. The OCS-SK2-HDMI-7 offers this technology in an affordable and versatile package for the PCB auditor, industrial inspection line or clinical teaching laboratory. Mounting & ControlsThe SK2-HDMI-7 is specifically designed to enhance the Omano line of stereo inspection systems, with a robust metal housing, C/CS Mount and a useful tripod screw attachment point. Improved functionality includes on-camera controls with intuitive, menu-driven buttons for cursor control, image save (to optional SD card), video freeze and Auto White Balance on/off. The cursor button will toggle between 5 different patterns including parallel vertical, horizontal, grid and cross-hair pointer. The camera features a standard C-mount which will accept any standard c-mount adapter. The optional 0.37X reducing adapters shown above will mate with any 23mm smooth bore microscope eyeport or trinocular tube. Processing & OutputThe camera has fast white balance correction for excellent color reproduction and an output resolution of 1280 x 720 in format. With 30 FPS live response rate, the OCS-SK2-HDMI-7 quickly reacts to changing lighting conditions in any life science, clinical or material application, sending a sharp video output to an HDMI monitor. An SD card memory slot offers additional storage capacity (SD card not included)..MicroscopeThe Omano OM10K zoom microscope provides 7x-45x zoom range with coarse/fine focus and click stops that enable the operator to dial in the exact same level of magnification for different specimens for easy comparison. Each microscope includes a 0.5x Barlow lens which enables maximum working distance of 6.75". An 80 LED ring light is included. Optional illumination upgrades include dual pipe LED or 64 and 144 LED ring illumination systems.StandThe Omano V3 pole stand's ergonomic design includes beveled leading edges for operator comfort. It features a tall, 12" vertical pole for extended working distances and a 12" x 12" base with rubber feet to protect your worktop. A safety collar and black/white contrast plate is also included.Camera AccessoriesAccessories include power supply, remote control, HDMI cable. Microscope AccessoriesIncluded 80 LED fluorescent ring light. Please note: Monitor not included.
    Feed - Custom Label 1 <100

  • SK2 Calibration Slide Micrometer, 5-Target
    General
    Brand OptixCam
    SKU OCS-SK2-CSM2
    Feed - Title OptixCam SK2 Calibration Slide Micrometer, 5-Target
    Feed - Description D3K2-1.4The new OptixCam Summit D3K Series 14MP digital microscope camera introduces SuperSpeed USB 3.0 technology to the world of digital microscopy. Faster data transfer and more efficient power consumption make for an efficient and versatile imaging solution for educators, life science researchers, healthcare professionals, and many other professional disciplines. Windows PC and MAC users will benefit from easy-to-use feature-rich software, accurate color, clarity and image detail, while USB 3.0 data transfer maximizes productivity and user engagement.Advantages of USB 3.0USB 3.0, also known as SuperSpeed
    Feed - Custom Label 1 <100

  • Optixcam SK2 Collar Adapter Kit
    General
    Brand OptixCam
    SKU OCS-SK2-COLLARS
    Warranty 1 Year
    Compatible With DJFOB
