OptixCam Summit KK2-1.3 1.3MP Color Digital Microscope Camera

$ 59.00

List Price: $109.00

Starting at: $59.00

SKU: TMS-KK2-1.3

Availability: In stock

  • 1.3 MP with excellent color resolution
  • Windows-only
  • Stills & Live Image video
  • Integrated 23mm ocular tube

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

Summit KK2-1.3 1.3MP Windows-Only Color Digital Camera   $59.00
  • $25.00

Included in Bundle

Camera: Summit KK2-1.3 1.3MP Windows-Only Color Digital Camera

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Summit KK2-1.3 1.3MP Color Digital Microscope Camera main
  • Summit KK2-1.3 1.3MP Color Digital Microscope Camera size
  • Summit KK2-1.3 1.3MP Color Digital Microscope Camera rear
  • Summit KK2-1.3 1.3MP Color Digital Microscope Camera installed
  • Summit KK2-1.3 1.3MP Color Digital Microscope Camera sample


The new OptixCam Summit Series KK2-1.3MP digital microscope camera is a terrific way to turn any microscope into a fun and exciting learning tool for kids of all ages. Designed for students and young explorers, this sturdy and affordable little camera will out-perform any other camera in its price range. When used in place of a standard microscope eyepiece, students can now capture vivid images of that sea shell from vacation, the backyard butterfly, a drop of pond water, or Grandpa's coin collection.

It works well with Windows operating systems and the software installs quickly so kids can start capturing images and video. The camera includes a 23.2mm smooth bore ocular mount for mounting on the eyetube or trinocular port of most modern microscopes. We highly recommend this camera for the hobbyist, coin-collector, home-school educator and all general microscopy use.

Summit KK2 Series Features

The brand new OptixCam Summit K2 Series cameras represent the latest innovation in digital microscopy, built to meet the documentation demands of routine life science, industrial and educational applications at very competitive price-points. Designed around the proven Aptina MT9T001 CMOS color sensor, they share a broad dynamic range, progressive scan, accurate color replication and optimal image quality.


The included software for Windows provides for excellent color rendering and fast image processing especially when capturing multiple images. Simple, intuitive and easy-to-use controls offer image capture, notation, geometric measuring and storage in JPG, BMP, TIFF, RAW format. The software also includes auto white balance, color enhancement, anti-flicker and other image-enhancing benefits. This software is not MAC-compatible.


Accessories include Software CD and USB2.0 cable. Camera dimensions: 27mm Dia. x 42mm Length. Package Wt. .4 lb.

Specifications of Component Options

Select a component below to view related specifications.

  • Summit KK2-1.3 1.3MP Windows-Only Color Digital Camera
    Brand OptixCam
    SKU OCS-KK2-1.3
    Warranty 1 Year
    Product Weight 2.0000
    Product Display
    New Yes
    Sensor Type CMOS
    Sensor Size 1/3 Inch
    Color/Monochrome Color
    Pixel Pitch 3.6 µm x 3.6 µm
    Sensor Color Depth 8bpp / 24bit RGB
    Scan Mode Progressive
    Shutter Electronic, Rolling Shutter
    Camera Mount Ocular Mount
    Resolution 1.3 Megapixel, 1280x1024 pixels
    Camera Output Resolutions 1280 X 1024; 640 X 512; 320 X 256
    FPS @ Max Res 7.5fps @ 1280 x 1024
    FPS @ Min Res 12.5fps @ 800 x 600
    Camera Interface USB 2.0
    White Balance Automatic, Manual
    Software Included OptixCam K2View
    Driver API Compatibility DirectX, TWAIN
    Power Source USB Powered
    File Formats JPEG
    Exposure Control Automatic, Manual
    Exposure Time 2000ms-0.14Ms
    Operating Temperatures 10°C ~ 50°C
    Operating Humidity 30% ~ 80% RH
    Storage Temperature -20°C ~ 60°C
    Other Details
    Included Accessories 0.5X 23mm Ocular adapter, Software CD
    Supported Operating Systems Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+, Linux (kernel 2.6.26+)
    System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
    Certifications CE, UL
    Cable Length 1.8m (8ft)
    Camera Warranty 1 Year
    Software Support 6 Months
    Imaging Compatibility (with adapters) 23mm
