EMZ-250TRB 4.4X-28.1X Zoom Binocular Boom Microsurgical System

EMZ-250TRB 3X-20X Zoom Binocular Boom Microsurgical System

You pay: $0.00

$3,370.00

Meiji Techno

EMZ-250TRB 3X-20X Zoom Binocular Boom Microsurgical System

SKU: EMZ-250TRB

In stock FREE Shipping On Items Over $150
  • Trinocular 3X to 20X zoom magnification
  • SWF 12.5X eyepieces inclined 30 degrees for comfort
  • High-intensity LED incident illumination
  • Ergonomic boom stand allows 500mm of specimen height
  • 250mm working distance with included 0.35X Barlow lens
  • Trinocular configuration with C-mount adapter
  • Lifetime Limited Warranty

Select Package Options:

EMZ-18TRB Trinocular Zoom Microsurgical Head   $1,650.00
MA520 - 12.5x Super Widefield Paired Eyepieces   $150.00
MA600 Stereo Eyeshields (Pair)   $10.00
MA792 0.35x Barlow Lens, WD=250mm   $129.00
S-4200 Boom Stand   $525.00
F Focus Block with 84mm Ring   $250.00
C-Mount Adapter 0.6X for Meiji EMZ-8TR Series   $195.00
144 LED Ring Light, Variable Intensity by Section   $129.00
EMZ-8TR/PT#1 Trinocular Tube for increased FOV   $60.00

Included in Bundle

Microscope System: EMZ-18TRB Trinocular Zoom Microsurgical Head

Eyepieces: MA520 - 12.5x Super Widefield Paired Eyepieces

Eyeguards: MA600 Stereo Eyeshields (Pair)

Auxiliary Lens: MA792 0.35x Barlow Lens, WD=250mm

Stand: S-4200 Boom Stand

Focus Block: F Focus Block with 84mm Ring

Installed C-Mount Adapter: C-Mount Adapter 0.6X for Meiji EMZ-8TR Series

Illumination: 144 LED Ring Light, Variable Intensity by Section

Trinocular Tube: EMZ-8TR/PT#1 Trinocular Tube for increased FOV

* Required Fields

You pay: $0.00

$3,370.00

As low as: $3,098.00

Regular Price: $3,370.00

Add to Wish list
Created with Sketch. 30 Day Money Back Guarantee
Description

Details

Summary

The Meiji EMZ-250TRB zoom stereo boom micro-surgical system is ideally suited for the demanding requirements of a microsurgery operating room. The compact optical unit delivers clear, focused images and the generous 250mm working distance gives the physician optimum maneuverability for performing delicate surgical techniques. The ergonomic S4200 boom stand and 8W LED incident illumination offer a shadow-free secure observation platform. Limited Lifetime Warranty.

Microscope Head

The EMZ-250 head is based on the EMZ-5, easily the most popular Meiji stereo microscope head. This workhorse model builds on that reputation while offering great quality and an affordable purchase point. The parfocal zoom range is 3X - 20X with dual-sided zoom controls and a field of view range of 57mm - 8.8mm. The working distance is 200mm for ease of maneuvering surgical instruments, a critical factor for any microsurgery procedure.

The head is inclined at a comfortable 30° and includes interpupillary adjustment of 54mm-75mm to fit a wide variety of users. Dual eyepiece diopters ofer +8D / -7D of individual adjustment range resulting in much less eye fatigue. The head rotates through 360° allowing flexible observation positions for the physician. This trinocular version features an internal prism to re-direct the optical beam and a 0.6X C-mount Adapter.

Stand

The Model S-4200 single-arm boom stand is one of our favorites. Well-designed with a compact 265mm x 265mm (10.4") footprint, it features 530mm (20.8") of horizontal reach and 610mm (24") of height, it is comfortable to use with beveled corners and a tall post which can accept specimens up to 500mm in size.

System Components:

EMZ-250 TRINOCULAR - EMZ-18TRB zoom trinocular microscope body, MA520 SWF 12.5X Eyepieces, MA792 0.35X Barlow Lens W.D. 250mm, S-4200 Boom Stand, 144 LED Ring Illuminator, F focusing block, EMZ-8TR/PT#1 trinocular tube, MA151/8TR C-mount adapter.

Additional Information

Additional Information

Brand Meiji Techno
SKU EMZ-250TRB
Short Description
  • Trinocular 3X to 20X zoom magnification
  • SWF 12.5X eyepieces inclined 30 degrees for comfort
  • High-intensity LED incident illumination
  • Ergonomic boom stand allows 500mm of specimen height
  • 250mm working distance with included 0.35X Barlow lens
  • Trinocular configuration with C-mount adapter
  • Lifetime Limited Warranty
