Meiji Techno EMF-2 Fixed 2X Mag Stereo Binocular Head

List Price: $570.00

Starting at: $510.00

SKU: EMF-2

Availability: In stock

  • Meiji's most popular fixed stereo microscope head
  • 108mm working distance
  • Rotatable through 360°
  • Binocular format
  • MA502 10X Eyepieces are included
  • Lifetime Limited Warranty
  • Shown with optional eyeshields

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

EMF-2 Fixed 2X Mag Stereo Binocular Head   $360.00
MA502 - 10X Super Widefield Paired Eyepieces   $150.00
  • $10.00

Included in Bundle

Type of Head: EMF-2 Fixed 2X Mag Stereo Binocular Head

Eyepieces: MA502 - 10X Super Widefield Paired Eyepieces

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

Description

The EMF-2 stereo head is an economical yet quality Meiji product, offering 20x magnification and eyetubes inclined 45 degrees. The eye tubes also rotate 360-degrees and include dual dioptric adjustments. Interpupillary eye adjustment is 54mm - 75mm and working distance is 108mm. Higher magnification is available with optional eyepieces and objectives.

MA502 10X Eyepieces are included with the head.

Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • EMF-2 Fixed 2X Mag Stereo Binocular Head
    SKU EMF2
    Head
    Head Type Binocular
    Optical Design Greenough Converged
    Magnification Type Fixed
    Ocular Angle 45°
    Ocular Tube Diameter 30.5 mm
    Diopter Adjustment Single
    Interpupillary Adjustment Arc (Seidentopf)
    Interpupillary Adjustment Range 54mm - 75mm
    Head Rotation 360 Degrees
    Minimum Objective (X) 2
    Maximum Objective (X) 2
    Body
    Body Material All-Metal
    Head Ring Mount Diameter 84 mm
    Max Working Distance (standard) 108 mm

  • MA502 - 10X Super Widefield Paired Eyepieces
    SKU MA502
    Warranty Meiji Limited Lifetime Warranty
    Notes 30.5mm OD, 25mm reticle mount, Fits MEIJI EM SERIES ONLY
    Compatible With EM*
    Eyepiece Magnification 10x

  • MA600 Stereo Eyeshields (Pair)
    SKU MA600
