Motic BA310P Polarizing Compound Microscope

List Price: $3,640.00

Starting at: $3,276.00

SKU: BA310P

Availability: In stock

  • EC Plan Strain-Free Objectives (4X, 10X, 40X S, 60X S)
  • Color-Corrected Infinity Optical system
  • Reversed quadruple nosepiece
  • External 6V 30W Halogen illumination
  • Rotatable analyzer and Bertrand lens
  • Strain-free condenser N.A. 0.9/0.13
  • Lifetime Limited Warranty
Select package options

Click on to learn more about the option * signifies required items

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Motic BA310BP TRinocular Polarizing Compound Microscope
  • Motic BA310BP TRinocular Polarizing Compound Microscope trinocular
Description

Summary

The Motic BA310POL is designed for materials science professionals examining birefringent specimens with efficiency and repeatability. Innovative features include a new generation of EC Plan Strain-Free objectives set in a reversed quadruple nosepipece and 10X high-eyepieces set in a 30-degree inclined Siedentopf binocular or trinocular head. Full polarization includes a rotatable analyzer with Bertrand lens and rotatable polarizer. Standard 6V30W Halogen illumination, a strain-free condenser and large mechanical stage round out an economical, versatile system suited for a wide range of petrography, minerology and materials science applications.

Optics

The optical system is designed around a new generation of Color Corrected Infinity System EC Plan Strain-Free objectives (4X, 10X, 40X S, 60X S) set in a reversed quadruple nosepiece. These new lenses are multilayer-coated for improved color fidelity and image contrast. A fully corrected tube lens includes a focusable and centerable Bertrand lens, 360-degree graduated analyzer for optimum image extinction, and a DIN-compliant compensator slot accepts all established compensators. widefield high-eyepoint N-WF PL10X eyepieces feature 20mm field of view, dual dioptric adjustment, and one eyepiece includes a fixed crosshair reticle.

Stage & Focus

The hard-coated rotating stage is 160mm in diameter and features ball bearings for smooth rotation through 360 degrees, with 1-degree graduations for quick, precise orientation and reference. Focusing includes concentric coarse/fine control knobs operating machined rack and pinion gearing for smooth, controlled movement. Safety features include a rack-stop to prevent damage to the objective or slide, and a slip clutch to minimize the risk of damage due to over-extension.

Illumination

Our Motic BA310POL comes standard with 6V/30W Koehler Halogen illumination, along with an adjustable field diaphragm and aperture diaphragm for repeatable, shadow-free illumination. A strain-free swing-out condenser with N.A. 0.90/0.13 and fully rotatable and graduated polarizer allow optimum lighting refinement.

Accessories

Owners Manual, power cord, Hex Key, Insertion plate, Blue filter, Eyecups, Vinyl dust cover.

SKU MODEL MOTIC #
BA310BP Binocular Polarzing 1100100402241
BA310TP Trinocular Polarizing 1100100402261
Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • BA310BP Binocular Polarizing Compound Microscope

    BA310TP Trinocular Polarizing Compound Microscope
    SKU BA310BPBA310TP
    Warranty Limited Lifetime WarrantyLimited Lifetime Warranty
    MAP Copy MAP - MoticMAP - Motic
    System
    System Type Brightfield, PolarizingBrightfield, Polarizing
    Optical Design DIN 160mmDIN 160mm
    Number of Heads Single Primary HeadSingle Primary Head
    Head
    Head Type BinocularTrinocular
    Head Rotation 360 Degrees360 Degrees
    Ocular Angle 30°30°
    Diopter Adjustment DualDual
    Interpupillary Adjustment Arc (Seidentopf)Arc (Seidentopf)
    Interpupillary Adjustment Range 55-75 mm55-75 mm
    Trinocular Type Switchable Beam-SplitSwitchable Beam-Split
    Ocular Tube Diameter 30 mm30 mm
    Body
    Nosepiece Orientation ReversedReversed
    Nosepiece Style Quadruple (4)Quadruple (4)
    Focus Controls Coarse & Fine, CoaxialCoarse & Fine, Coaxial
    Focus Mechanism Rack & PinionRack & Pinion
    Focus Control Location Dual AmbidextrousDual Ambidextrous
    Focus Controls Graduated? YesYes
    Focus Control Safety Stop Slip ClutchSlip Clutch
    Stage Type Circular RotatableCircular Rotatable
    Stage Features 360deg Indexed, Slide Holder (spring-loaded)360deg Indexed, Slide Holder (spring-loaded)
    Stage Dimensions 160mm Diameter160mm Diameter
    Stage Range Graduated? YesYes
    Configuration
    Includes Eyepieces? YesYes
    Included Eyepiece Quantity 22
    Included Eyepieces (X) 10X10X
    Eyepiece Style SWF Super Widefield (FN 20mm)SWF Super Widefield (FN 20mm)
    Min Standard Mag 40X40X
    Max Standard Mag 600X600X
    Included Objectives (Qty) 44
    Objective Lens PlanPlan
    Included Objective Types Brightfield, Strain-free (Polarizing)Brightfield, Strain-free (Polarizing)
    Objective 1 Description EC PLAN 4XEC PLAN 4X
    Objective 1 N.A. 0.100.10
    Objective 1 W.D. 15.90mm15.90mm
    Objective 2 Description EC PLAN 10XEC PLAN 10X
    Objective 2 N.A. 0.250.25
    Objective 2 W.D. 17.40mm17.40mm
    Objective 3 Description EC PLAN 40XEC PLAN 40X
    Objective 3 N.A. 0.650.65
    Objective 3 W.D. 0.50mm0.50mm
    Objective 4 Description EC PLAN 60XEC PLAN 60X
    Objective 4 N.A. 0.800.80
    Objective 4 W.D. 0.35mm0.35mm
    Condenser
    Condenser Type Abbe BrightfieldAbbe Brightfield
    Condenser Features Centerable, Iris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder, Swing-out Secondary LensCenterable, Iris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder, Swing-out Secondary Lens
    Condenser N.A. 0.9 mm0.9 mm
    Filters Included BlueBlue
    Illumination
    Illumination Type HalogenHalogen
    Illumination Style TransmittedTransmitted
    Collector Type KohlerKohler
    Collector Features Field DiaphragmField Diaphragm
    Transmitted Light Type HalogenHalogen
    Transmitted Light Specification 6V 30W6V 30W
    Transmitted Light Control VariableVariable
    Power Supply 100 - 240 VAC100 - 240 VAC
    Polarizer Description Fully rotatable with 90-degree click-stopFully rotatable with 90-degree click-stop
    Analyzer Description 360-Degree graduated, rotatable360-Degree graduated, rotatable
    Polarizing Accessories Bertrand Lens (conoscopic observation)Bertrand Lens (conoscopic observation)
    Compatibility
    Imaging Compatibility (with adapters) 23mm , C-Mount23mm , C-Mount
    Accessories
    Included Extras Dust Cover, Immersion OilDust Cover, Immersion Oil
