Motic BA310MET Metallurgical Binocular Compound Microscope

List Price: $3,570.00

Starting at: $3,213.00

SKU: BA310MET

Availability: Backorder

  • M Plan LWD Objectives (5X, 10X, 20X, 50X)
  • Color-Corrected Infinity Optical system
  • Reversed quintuple nosepiece
  • Epi illuminator with 12V 50W Halogen lamp house
  • Optional 12V 3W LED conversion module
  • Accepts specimens up to 30mm thick
  • Recommended for Engineering disciplines

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

  • $135.00
  • $894.00

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Motic BA310MET Metallurgical Microscope
  • Motic BA310MET Metallurgical Microscope trinocular
  • Motic BA310 MET LED Module
Description

Summary

The new Motic BA310MET Advanced Metallurgical Series is designed to meet the performance demands of engineering professionals who need to study opaque samples like minerals, metals and building materials. Innovative features include a new generation of metallurgical M Plan achromatic objectives set in a reversed quintuple nosepipece and 10X eyepieces set in a 30-degree inclined Siedentopf binocular or trinocular head. A standard Epi-illuminator with 12V50W Halogen lamp house can be field-converted to 3W LED illumination with a simple plug-in module. Included field and aperture diaphragms enhance a uniquely versatile and functional system for a wide range of engineering and professional disciplines.

Optics

The optical system is designed around a new generation of Color Corrected Infinity System M Plan Achromatic objectives (5X, 10X, 20X, 50X) set in a reversed quintuple nosepiece. These new lenses are multilayer-coated for improved color fidelity and image enhancement. Widefield high-eyepoint N-WF10X eyepieces feature dual dioptric adjustment, 55mm x 75mm of interpupillary adjustment and include eyecups. The M Plan objectives also offer greatly increased working distances (8.2mm at 500X), rewarding user efforts with contaminant-free lenses and sharp visual results.

Stage & Focus

A hard-coated 180mm x 140mm rectangular stage allows exact sample positioning across 75mm x 50mm of XY movement, operated by coaxial drop-down controls. Focusing includes coarse/fine controls driving machined rack and pinion mechanics with a graduated scale of 0.002mm for precise image detail. Safety features include a rack-stop to prevent damage to the objective or sample and a slip clutch to minimize the risk of damage due to over-extension. Can accept specimens up to 30mm thick.

Illumination

Our new Motic BA310MET Metallurgical series comes standard with 12V/50W Halogen illumination system with built-in power supply and lamp house. Like the Elite series, the innovative system can be converted from Halogen to LED simply by plugging an optional LED module (4500K or 6000K) into the Halogen lamp socket. The power supply is housed separately from the microscope to minimize unnecessary heat transfer and the Epi illuminator includes field and aperture diaphragms, both of which can be adjusted to minimize reflections and optimize performance.

Accessories

Owners Manual, power cord, Hex Key, Eyecups, Vinyl dust cover.

SKU MODEL MOTIC #
BA310B-Met Binocular Metallurgical 1100100402144
BA310T-Met Trinocular Metallurgical 1100100402045



Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • BA310B-Met Binocular Metallurgical Compound Microscope

    BA310T-Met Trinocular Metallurgical Compound Microscope
    SKU BA310B-MetBA310T-Met
    Warranty Limited Lifetime WarrantyLimited Lifetime Warranty
    MAP Copy MAP - MoticMAP - Motic
    System
    System Type BrightfieldBrightfield
    Optical Design Infinity CorrectedInfinity Corrected
    Number of Heads Single Primary HeadSingle Primary Head
    Head
    Head Type BinocularTrinocular
    Head Rotation 360 Degrees360 Degrees
    Ocular Angle 30°30°
    Diopter Adjustment DualDual
    Interpupillary Adjustment Arc (Seidentopf)Arc (Seidentopf)
    Interpupillary Adjustment Range 55-75 mm55-75 mm
    Trinocular Type Switchable Beam-SplitSwitchable Beam-Split
    Ocular Tube Diameter 30 mm30 mm
    Body
    Nosepiece Orientation ReversedReversed
    Nosepiece Style Quintuple (5)Quintuple (5)
    Focus Controls Coarse & Fine, CoaxialCoarse & Fine, Coaxial
    Focus Mechanism Rack & PinionRack & Pinion
    Focus Control Location Dual AmbidextrousDual Ambidextrous
    Focus Controls Graduated? YesYes
    Focus Control Safety Stop Slip ClutchSlip Clutch
    Stage Type Mechanical XYMechanical XY
    Stage Features Fingertip Controls, Full Stage XY, Slide Holder (spring-loaded)Fingertip Controls, Full Stage XY, Slide Holder (spring-loaded)
    Stage Dimensions 180mm x 140mm180mm x 140mm
    Stage Range of Movement (XY) 75mm x 50mm75mm x 50mm
    Stage Range Graduated? YesYes
    Configuration
    Includes Eyepieces? YesYes
    Included Eyepiece Quantity 22
    Included Eyepieces (X) 10X10X
    Eyepiece Style SWF Super Widefield (FN 20mm)SWF Super Widefield (FN 20mm)
    Min Standard Mag 50X50X
    Max Standard Mag 500X500X
    Included Objectives (Qty) 44
    Objective Lens PlanPlan
    Included Objective Types MetallurgicalMetallurgical
    Objective 1 Description M PLAN 5XM PLAN 5X
    Objective 1 N.A. 0.130.13
    Objective 1 W.D. 11.511.5
    Objective 2 Description M PLAN 10XM PLAN 10X
    Objective 2 N.A. 0.300.30
    Objective 2 W.D. 6.806.80
    Objective 3 Description M PLAN 40XM PLAN 40X
    Objective 3 N.A. 0.400.40
    Objective 3 W.D. 11.1011.10
    Objective 4 Description M PLAN 50XM PLAN 50X
    Objective 4 N.A. 0.550.55
    Objective 4 W.D. 8.208.20
    Condenser
    Condenser Type Abbe BrightfieldAbbe Brightfield
    Condenser Features Iris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder, Swing-out Secondary LensIris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder, Swing-out Secondary Lens
    Condenser N.A. 0.9 mm0.9 mm
    Illumination
    Illumination Type HalogenHalogen
    Illumination Style Epi MetallurgicalEpi Metallurgical
    Collector Type KohlerKohler
    Collector Features Field DiaphragmField Diaphragm
    Incident Light Type HalogenHalogen
    Incident Light Specification 12V50W12V50W
    Incident Light Control VariableVariable
    Power Supply 100-240VAC120V AC
    Compatibility
    Imaging Compatibility (with adapters) 23mm , C-Mount23mm , C-Mount
    Accessories
    Included Extras Dust CoverDust Cover

  • BA310MET Erect Image Configuration - Trinocular only

    BA310MET Plan Achromatic Objective, 100X, MPN 1101001704512
    SKU BA310MET-ERMOBJ-PL-100X
    Warranty  Omano Limited Lifetime Warranty
    MAP Copy MAP - MoticMAP - Motic
    Objectives
    Objective Lens  Plan
    Objective Lens Power  100x
