Next-Generation Fluorescence Imaging

The TC-5500CW (Binocular) and TC-5600CW (Trinocular) series represent the pinnacle of inverted biological microscopy, specifically engineered for applications in oncology, immunology, genetics, and cell cytology. By integrating Meiji Techno’s world-class Japanese optics with the award-winning CoolLED PE-300 Series, these microscopes offer a sustainable, high-intensity alternative to traditional mercury and xenon lamps.

Whether you are performing routine laboratory work or high-level university research, the TC-5000 series provides a stable, repeatable, and mercury-free environment for imaging everyday fluorophores like DAPI, FITC, TRITC, and Cy5.

CoolLED PE-300 Series: The New Standard in Illumination

Traditional gas discharge lamps suffer from intensity decay and heat issues. The integrated PE-300 LED system revolutionizes your workflow:

• Stable & Repeatable: Constant intensity over a 25,000-hour lifespan ensures consistent data for longitudinal studies.
• Precise Control: Adjust output in 1% increments (0-100%) directly from the control pod—no ND filters required.
• Instant Performance: No warm-up or cool-down periods; instant on/off functionality acts as a digital shutter to prevent photobleaching.
• Broad Spectrum: Complete coverage from UV (DAPI) to the Red region (Cy5).

System Features & Specifications

• Optical System: Computer-Aided Design (CAD) frame and optics with Semi-Apo Plan Fluorescence objectives.
• Viewing Heads: Siedentopf-type binocular (30°) or trinocular (45°) for ergonomic viewing; optional tilting ergonomic heads available.
• Fluorescence Module: Six-position turret including three Chroma Fluorochromes (Basic Blue and Basic Green filters included).
• Stage Design: Large 180mm x 245mm stage with a replaceable glass insert and transparent plate for easy objective identification.
• Build Quality: Compact wedge-shaped cast aluminum alloy frame with a chemical-resistant baked enamel finish for maximum stability.

Choose Your Configuration

Waveband Configurations

To match your existing filter sets, the PE-300 system is available in two DAPI excitation configurations:

• 365nm: Optimized for microscopes using single-band (SB) filter sets.
• 400nm: Optimized for microscopes using multi-band (MB) filter sets.

Environmental & Operational Advantages

""The TC-5000 series reduces energy consumption by up to 80% compared to conventional illuminators while eliminating the risks and disposal regulations associated with mercury bulbs.""

Upgrade to Sustainable Fluorescence Today

Configure your TC-5500CW/TC-5600CW system to fit your specific fluorophore requirements. Affordable through standard lab consumables budgets.

Contact Meiji Techno America for a customized quote.
