Omano OMFL400 Fluorescence Compound Microscope

List Price: $4,338.00

Our Price: $2,395.00

SKU: OMFL400

Availability: In stock

  • Quintuple nosepiece
  • 4 Plan Objectives (PL4x, PL10x, PL40xS, PL100xS oil)
  • 2 FL objectives (FL25xG, FL40xSG)
  • Included centering telescope
  • 100W Mercury lamp and Brightfield halogen
  • Included trinocular adapter
  • Lifetime Limited Warranty

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Omano OMFL400 Fluorescence Compound Microscope
  • Omano OMFL400 Fluorescence Compound Microscope filters
  • Omano OMFL400 Fluorescence Compound Microscope objectives
  • Omano OMFL400 Fluorescence Compound Microscope stage
  • Omano OMFL400 Fluorescence Compound Microscope eyepieces
Description

Summary

The Omano OMFL400 is an upright, trinocular fluorescence microscope that is a good quality workhorse for fluorescence applications and photomicrography. It includes six premium objective lenses for optical clarity, a T-Mount photo tube with two magnification settings and integrated fine focus and two excitation filters - blue and green. Illumination includes both a 100W mercury arc lamp and 20W halogen for brightfield applications. maximum magnification is 1,000x. Limited Lifetime Warranty.<

Optics

The microscope has a trinocular Seidentopf viewing head that is inclined at an ergonomic 30° for greater comfort. There are two WF10x eyepieces with dual diopters and a phase centering, telescope. The T-Mount trinocular adapter has the useful addition of two switchable magnifications: 2.5x and 4x that enable use with appropriate SLR cameras. The microscope also features a quintuple, reverse-facing nosepiece and six objectives. They include four plan achromatic:PL4x, PL10x, PL40xS, PL100xS oil immersion and two fluorescence objectives: FL25x, FL40xS glycerin.

Stage & Focus

A graduated mechanical stage measures a generous 140mm x 160mm with right-hand, low position coaxial controls. The range of movement is 50mm x 75mm. Rack and pinion focusing includes coaxial coarse/fine focus controls on the right hand side.

Condenser & Illumination

The condenser is 1.25 N.A Abbe with iris diaphragm. Illumination includes a 100W mercury arc lamp with rotatable filter holder and in-base 6V20W brightfield halogen. Excitation filters include Blue: 420-485nm and Green: 460-550nm.

Accessories

Accessories include blue and green contrast filters, 16cc immersion oil, spare fuse, bulb, manual and dust cover.

Shipping Wt. and dimensions: 33 Lb. 24"x18"x18".

Specifications

OMFL400 Fluorescence Compound Microscope
General
SKU OMFL400
Short Description
  • Quintuple nosepiece
  • 4 Plan Objectives (PL4x, PL10x, PL40xS, PL100xS oil)
  • 2 FL objectives (FL25xG, FL40xSG)
  • Included centering telescope
  • 100W Mercury lamp and Brightfield halogen
  • Included trinocular adapter
  • Lifetime Limited Warranty
Warranty Omano Limited Lifetime Warranty
System
System Type Brightfield, Epi-Fluorescence
Optical Design DIN 160mm
Head
Head Type Trinocular
Ocular Angle 30°
Diopter Adjustment Single
Interpupillary Adjustment Arc (Seidentopf)
Interpupillary Adjustment Range 55-75 mm
Ocular Tube Diameter 23 mm
Body
Nosepiece Orientation Reversed
Nosepiece Style Quintuple (5)
Focus Controls Coarse & Fine, Coaxial
Focus Mechanism Rack & Pinion
Focus Control Location Dual Ambidextrous
Stage Type Mechanical XY
Stage Features Fingertip Controls, Slide Holder (spring-loaded)
Configuration
Includes Eyepieces? Yes
Included Eyepiece Quantity 3
Included Eyepieces (X) 10X
Eyepiece Style WF Widefield (FN 18mm)
Min Standard Mag 40X
Max Standard Mag 1000X
Objectives
Included Objectives (Qty) 6
Objective Lens Plan
Included Objective Types Brightfield, Epi-Fluorescence
Condenser
Condenser Type Abbe Brightfield
Condenser Features Iris Diaphragm, Rack & Pinion Focus, Swing-out Filter Holder
Condenser N.A. 1.25 mm
Illumination
Illumination Type Fluorescent, Mercury Arc
Illumination Style Transmitted, Epi-Fluorescent
Collector Type Kohler
Collector Features Field Diaphragm
Transmitted Light Type Halogen
Transmitted Light Specification 6V 20W
Transmitted Light Control Variable
Coaxial Light Type Mercury Arc
Coaxial Light Specification 100W
Coaxial Light Control Variable
Power Supply 110V -240VAC Auto-Switching
Epi-Fluorescence
Epi-Fluorescence System Details INSERT EPI-FLUORESCENCE DETAILS HERE
Compatibility
Imaging Compatibility (with adapters) 23mm , C-Mount, T-Mount
Available Imaging Mounts 0.4X C-Mount
Accessories
Included Extras Dust Cover, Spare Bulb, Spare Fuse
