Omano Reticle, 25mm Linear

List Price: $98.00

Our Price: $55.00

$ 55.00


Availability: In stock

  • 25mm Reticle with 10mm Linear Scale
  • 100 divisions = 10mm
  • Fits OMM300 compound, OM2300S, OMXTL, OM99 stereo microscopes

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Omano Reticle, 25mm Linear

For accurate and convenient microscopic calibration and measurements we offer our 25mm linear reticle - Linear Scale: 100 divisions = 10mm

We also offer the following optional reticles:

Grid Scale: 10 divisions per side = 1mm, 100 cells

Cross (Pinwheel) Scale: 0-6-0, 10 divisons = 1mm

0 0

Reticle, 25mm Linear
Brand Omano
Short Description
  • 25mm Reticle with 10mm Linear Scale
  • 100 divisions = 10mm
  • Fits OMM300 compound, OM2300S, OMXTL, OM99 stereo microscopes
Notes For OM99, OMXTL, OM2300S
