Stand

The V10 is a single arm stand that is popular, thanks to a 4" extension bar that allows precision horizontal movements of the microscope head. Instead of having to shift the entire horizontal arm, simply turn the extension bar control knob at the end of the arm. The stand includes a solid metal, hanging bar bracket which permits unlimited tilting of the microscope head.

A neat feature on the hanging bar bracket is a spring-loaded adjustment lever that enables the lever to be moved out of the way without releasing the pre-set position of the microscope head.

Hanging bar

Select the hanging bar appropriate for your focus ring and microscope.

• 20mm fits Meiji Techno EMZ and EMT microscope head
• 25mm Omano OM10k monocular zoom microscope
• 30mm fits Omano OM99 stereo microscope
• 32mm fits Omano OM2300S stereo microscope

Please note: Focus block is sold separately

Omano Stereo Boom Stand Comparison

• 	V10 Boom Stand
  General
  Brand	Omano
  SKU	V10
  Stand
  Stand Class	Boom
  Stand Type	Single Arm Boom
  Base Width	254 mm
  Base Depth	254 mm
  Post Height	464 mm
  Post Diameter	38 mm
  View Center to Post Distance	527 mm
  Physical Construction	Metal Tube
  Coating Type (Stand)	Durable Powdercoat
  Hanging Bar Style	Articulable

• 	OMHB20 Hanging Bar	OMHB25 Hanging Bar	OMHB30 Hanging Bar	OMHB32 Hanging Bar
  General
  Brand	Omano	Omano	Omano	Omano
  SKU	OMHB20	OMHB25	OMHB30	OMHB32
  Feed - Title	Omano OMHB20 Hanging Bar	Omano OMHB25 Hanging Bar	Omano OMHB30 Hanging Bar	Omano OMHB32 Hanging Bar
  Feed - Description	StandThe V7 articulating boom arm can reach almost 3 feet yet folds into a 13 x13" space when not in use. The base plate version weighs in at 57 lb, while the optional C-clamp version weighs 25 lb. Well-balanced and stable with smooth controlled movement, it has a removable first piece of the articulating arm that achieves even greater stability. The pole stands 21" high and the articulating arm has an effective horizontal extension of 35". The C-clamp version can secure to workbenches up to 2.5 inches thick. As with most Omano boom stands, a hanging bar is included that enables angled viewing positions. The hanging bar bracket is spring-loaded so that the lever can be moved out of the way without having to release the pre-set position of the microscope head.Hanging barSelect the hanging bar appropriate for your focus block and microscope. 20mm fits Meiji Techno EMZ and EMT microscope head25mm Omano OM10k monocular zoom microscope30mm fits Omano OM99 stereo microscope32mm fits Omano OM2300S stereo microscopePlease note a focus block is sold separately	FREE Post Sale telephone service with Live Human!This industrial microscope inspection system combines the vivid, high-speed response of the new 1080PU series HDMI & USB2.0 digital microscope camera with our brand new Omano VIDZ-650 6X-50X zoom inspection lens and your choice of seven different Omano boom stands.The new Optixcam OCS-HDMI-1080PU brings simultaneous HDMI and USB2.0 output to professionals who require high-definition CMOS color microscopy documentation. Like its HDMI-output cousin (NH1080P), the 1080PU is an industrial-designed, stand-alone imaging solution offering 2.0MP still capture to an SD card or USB2.0 output, and 1080p video preview resolution with superb color reproduction and real-time frame rates of 60 fps via HDMI, or 30 fps via USB2.0 or SD card output. Camera FeaturesHDMI (High-Definition Multimedia Interface) technology brings a number of key benefits to digital microscopy, including richer color definition, better signal integrity, greater bandwidth capacity, encryption protocols and high-definition video. The OCS-HDMI-1080PU offers this technology in an affordable and versatile package for the biology classroom, industrial inspection line or clinical teaching laboratory. The camera offers direct streaming to an HDMI monitor without the complexity of computer software, making it an ideal imaging solution for fast-paced industrial environments and assembly line inspection stations.Mounting & ControlsThe OCS-HDMI-1080PU is specifically designed to enhance the Omano line of stereo inspection systems, with a robust metal housing, C/CS Mount and two useful tripod screw attachment points. Improved functionality includes on-screen controls with intuitive, menu-driven buttons for RGB adjustment, White Balance, red and green cross-hair cursor symbology and Auto Exposure. Note: The SK2-CA037X camera adapter will be needed when mounting the NH1080 camera to any microscope with a smooth bore 23mm optical tube. Processing & OutputThe camera has fast white balance correction for excellent color reproduction and a 2.0MP maximum output resolution of 1920 x 1080 in BMP format. With 60 FPS live HDMI response rate, the OCS-HDMI-1080PU quickly reacts to changing lighting conditions in any life science, clinical or material application, sending a sharp video output to an HDMI monitor.For researchers needing in-depth image analysis, the camera also offers traditional USB2.0 output to a pc or mac operating environment for a host of processing options including 2-dimensional measurement, image stitching, extended depth of focus, segmentation, stacking and color composition. A tethered cable enables remote capture of still images to an SD card, sold separately.Microscope FeaturesThe Omano OM10K zoom microscope provides 7x-45x zoom range with coarse/fine focus and click stops that enable the operator to dial in the exact same level of magnification for different specimens for easy comparison. Each microscope also includes a 0.5x Barlow lens which enables maximum working distance of 6.75".Microscope StandsChoose from our most popular single-arm, dual-arm and articulating-arm microscope stands, including the V10, an economical single-arm stand with a 25" reach and a 2.5" fine-extension bar to precisely position the microscope and camera. The V6 offers the same 25" reach along with dual-arm maneuverability. The V7 expands that maneuverability to three dimensions with a spring-powered articulating arm, and the premium V15 brings 28" of fingertip effort and control, thanks to a dual-arm, machined ball bearing design.Camera AccessoriesAccessories include USB mouse, HDMI cable, USB2.0 cable, AC power supply, Software CD with manual and SDK. Camera dimensions: 3 x 2.75 X 3.6". dimensions: 10 X 6 X 3", 2 LBs.Microscope AccessoriesAccessories include OM10K zoom lens, 80LED Ring illuminator, focus block, V3 stand. details: 20 x 13 x 10", 12 Lb.	Omano OMHB30 Hanging Bar	Exclusive to Microscope.com - Ideal for Jewelers Euromex's NexiusZoom zoom stereo microscope head brings a new level of quality at a remarkably low price level. With optical quality comparable to the Olympus SZ-61 and the Nikon SMZ-645, the NexiusZoom is up to 60% cheaper and is highly recommended by Microscope.com. In this configuration, it is paired with our top of the range V15 dual arm boom stand that features 'Continuous Glide' ball bearing operation for a stereo microscope of unbeatable value.NexiusZoom OpticsWith HWF10x/22mm eyepieces, and superb optics, the NexiusZoom offers a thoroughly enjoyable viewing experience that minimizes eye strain. 0.67-45x zoom combines for standard magnification of 6.7x-45x, but remarkably, given the quality of the optics and additional lenses, the microscope can operate effectively from 3.35x-180x with full resolution. The standard field of view is 33mm-4.9mm with a working distance of 110mm. Maximum working distance is 187mm with a 0.5x barlow lens. NOTE: The NexiusZoom-Trincular microscope head features an internal beam-splitting prism system which directs light to both eyepieces and the trinocular camera port simultaneously, allowing for efficient and continuous observation and documentation. Available with binocular or trinocular microscope head. Trinocular includes 23mm smooth eyepiece adapter with optinla C-Mount adapters available.V7 Articulating StandThe V7 articulating boom arm can reach almost 3 feet yet folds into a 13 x13" space when not in use. The base plate version weighs in at 57 lb, while the optional C-clamp version weighs 25 lb. Well-balanced and stable with smooth controlled movement, it has a removable first piece of the articulating arm that achieves even greater stability. The pole stands 21" high and the articulating arm has an effective horizontal extension of 35". The C-clamp version can secure to workbenches up to 2.5 inches thick. As with most Omano boom stands, a hanging bar is included that enables angled viewing positions. The hanging bar bracket is spring-loaded so that the lever can be moved out of the way without having to release the pre-set position of the microscope head.Includes: NexiusZoom Microscope head, HWF10x/22 eyepieces and rubber eyecups, V7 stand, focus ring, hanging bar and dust cover.
  Feed - Custom Label 1	<100	<100	<100	<100
  If HB Required
  Hanging Bar Style	Articulable	Articulable	Articulable	Articulable
  If FB Mounts Direct
  Focus Block Mount Diameter	25 mm	25 mm	30 mm	32 mm
