Omano V15U U-Clamp Boom Stand

List Price: $559.00

$304.00

SKU: V15U-HB

Availability: In stock

  • Premium dual-arm microscope boom stand
  • U-Clamp tabletop attachment
  • 'Continuous Flow' ball-bearing motion
  • 28" Horizontal extension
  • Hanging bar for focus ring attachment
  • Lifetime Limited Warranty

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

V15U U-Clamp Boom Stand (On Backorder)   $279.00

Included in Bundle

Stand: V15U U-Clamp Boom Stand

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Omano V15U Clamp Boom Stand
  • Bearings - V15U Clamp Boom Stand
  • Omano V15U Clamp Boom Stand closeup
Description

Stand

The V15 is our premium stand, characterized by 'continuous glide', ball-bearing motion for effortless repositioning, perfect for electronics and circuit board inspection. The boom has dual horizontal arms of solid metal alloy and measures 28 inches when extended (including the hanging bar).

It also includes several thoughtful features not seen on comparable products. A solid metal hanging bar bracket allows unlimited tilting angles of the microscope head. The counter-weight is mounted with a rubber back stop to protect the bearing housing. A neat, spring-loaded adjustment lever on the hanging bar bracket enables the lever to be moved out of the way without releasing the pre-set position of the microscope head.

The V15 boom stand provides up to 13 inches of vertical working space and includes a heavy-duty C-clamp capable of securely mounting to work surfaces up to 2.5 inches thick.  The boom stand can also be configured with an optional base plate to rest on top of a workbench. The overall build-quality and solid steel construction will provide a lifetime of dependable performance.

Also available with a standard base.

Hanging bar

Select the hanging bar appropriate for your focus ring.
  • 20mm fits Meiji Techno EMZ and EMT microscope head
  • 25mm Omano OM10k monocular zoom microscope
  • 30mm fits Omano OM99 stereo microscope
  • 32mm fits Omano OM2300S stereo microscope


Note: Microscope head and focus block sold separately.

Omano Stereo Boom Stand Comparison

Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • V15U U-Clamp Boom Stand
    SKU V15U
    Stand
    Stand Class Boom
    Stand Type Dual Arm Boom
    Stand Features Ball-Bearing Glide, Counter-weighted, Tabletop U-Clamp
    Base Width 254 mm
    Base Depth 254 mm
    Post Height 464 mm
    Post Diameter 38 mm
    View Center to Post Distance 514 mm
    Physical Construction Solid Metal
    Coating Type (Stand) Durable Powdercoat
    If HB Required
    Requires Separate Hanging Bar? Yes
    Hanging Bar Style Articulable

  • OMHB20 Hanging Bar

    OMHB25 Hanging Bar

    OMHB30 Hanging Bar

    OMHB32 Hanging Bar
    SKU OMHB20OMHB25OMHB30OMHB32
    If HB Required
    Hanging Bar Style ArticulableArticulableArticulableArticulable
    If FB Mounts Direct
    Focus Block Mount Diameter 25 mm25 mm30 mm32 mm
