OptixCam Summit D3K2-3 3.1MP USB 3.0 High Speed PC / MAC Digital Microscope Camera

$ 388.00

List Price: $558.00

Starting at: $388.00

SKU: TMS-D3K2-3.1

Availability: Backorder

  • 3.1 MP with excellent color resolution
  • Up to 10X faster data transfer than USB2.0
  • Large 1/3" sensor for greater fidelity
  • Fast refresh rate for stills & Live Image video
  • Efficient power consumption for longer peripheral battery life
  • Integrated C-mount to fit most microscopes
  • PC / MAC Compatible (MAC OS limited to image capture only)
  • FREE telephone support

Price as configured: $0.00

Select package options

Click on to learn more about the option * signifies required items

Summit D3K2-3.1 3.1MP USB 3.0 High Speed Digital Microscope Camera   $349.00
Fixed 23mm Camera Adapter 0.37X for SK2 Series Cameras (On Backorder 11-30-18)   $39.00
  • $25.00
  • $59.00
  • $59.00
  • $39.00
  • $5.00

Included in Bundle

Camera: Summit D3K2-3.1 3.1MP USB 3.0 High Speed Digital Microscope Camera

Included C-Mount Adapter: Fixed 23mm Camera Adapter 0.37X for SK2 Series Cameras

Price as configured: $0.00

Not sure if this is the item you’re looking for? Ask our friendly experts!

(877) 409-3556

Live Chat

  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera
  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera box
  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera sensor
  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera usb 3 .0
  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera adapter
  • Summit DK3-3.1 3.1MP USB 3.0 Digital Microscope Camera mounted
Description

D3K2-3.1

The new OptixCam Summit D3K Series 3.1MP digital microscope camera introduces SuperSpeed USB 3.0 technology to the world of digital microscopy. Faster data transfer and more efficient power consumption make for an efficient and versatile imaging solution for educators, life science researchers, healthcare professionals, and many other professional disciplines. Windows PC and MAC users will benefit from easy-to-use feature-rich software, accurate color, clarity and image detail, while USB 3.0 data transfer maximizes productivity and user engagement.

Advantages of USB 3.0

USB 3.0, also known as SuperSpeed™ USB, is the latest generation of USB technology and delivers several key performance benefits. For example, USB 3.0 transfers data up to ten times faster than USB 2.0, resulting in quicker transfer of large image or video files and greater workflow efficiency. This is ideal for data-streaming applications found in the research lab or biology classroom. It also does away with the power drain common to USB2.0, resulting in less power used and longer battery life in laptops, tablets and peripherals.

Summit K2 Series Features

The Summit K2 series camera bring affordable digital microscopy to a wide range of documentation demands of routine life science, industrial and educational environments. Built around the proven Aptina MT9T001 CMOS color sensor, they share a broad dynamic range, progressive scan and 12-bit parallel resolution for accurate color reproduction and optimal image quality. All SK2 series cameras are CE and FCC certified.

All Summit K2 microscope cameras share a rugged aluminum alloy body fitted with different size Aptina CMOS sensors depending on the model. Advanced documentation and measuring software is included along with a C-mount adapter with 23mm smooth bore and 0.5X reducing lens to more closely match the captured image with the eyepiece view. Optional focusing lenses, calibration slide and 30mm and 30.5mm collars are available.

Software

The included PC / MAC compatible K2View software creates a complete imaging solution with intuitive camera controls, image capture and advanced options like annotation, geometric measuring and storage in JPG, BMP, TIFF, PNG, PCX AND TARGA format. The software also includes auto white balance, color enhancement, anti-flicker and other benefits. TWAIN and DirectX plug-ins are also included on the installation CD and are independent of the main driver, allowing discreet control of the camera for these applications.NOTE: MAC OS functionality is limited to image capture only. Measurements, annotation and other functions are not available.

Accessories

Accessories include K2View Software CD, C-mount adapter, 23.2mm smooth bore fixed reducing lens (0.5X), USB 3.0 cable. Camera dimensions: 80mm x 80mm x 38mm. Package Wt. 1.2 lb.
Specifications

Specifications of Component Options

Select a component below to view related specifications.

  • Summit D3K2-3.1 3.1MP USB 3.0 High Speed Digital Microscope Camera
    General
    Brand OptixCam
    SKU OCS-D3K2-3.1
    Warranty 1 Year
    Product Weight 2.0000
    Sensor
    Sensor Type CMOS
    Sensor Size 1/3 Inch
    Sensor Details Aptina AR0330(C) CMOS
    Color/Monochrome Color
    Pixel Pitch 2.2 µm x 2.2 µm
    Sensor Color Depth 8bpp / 24bit RGB
    Scan Mode Progressive
    Signal to Noise Ratio 39dB
    Sensitivity 1.9v/Lux-sec
    Dynamic Range 100dB
    A/D Conversion 12-bit Parallel, 8-bit RGB to PC
    Shutter Electronic, Rolling Shutter
    Camera
    Camera Mount C-Mount, Ocular Mount
    Resolution 3 Megapixel, 2048x1536 pixels
    Camera Output Resolutions 2048 x 1536; 1024 x 768; 680 x 510
    FPS @ Max Res 27.3 @ 2048x1534
    FPS @ Min Res 53.3 @ 1024x770
    Camera Interface USB 3.0
    White Balance Automatic, Manual
    Software Included OptixCam K2View
    Driver API Compatibility DirectX, TWAIN
    Power Source USB Powered
    File Formats BMP, JPEG, Own Proprietary, PNG, TGA, TIFF
    Exposure Control Automatic, Manual
    Exposure Time 2000ms-0.128s
    Operating Temperatures 10°C ~ 50°C
    Operating Humidity 30% ~ 80% RH
    Storage Temperature -20°C ~ 60°C
    Other Details
    Included Accessories 0.5X 23mm DIN Adapter, Software CD
    Supported Operating Systems Windows 8, Windows 7, Windows Vista, Windows XP SP3, Mac OSX 10.7+, Linux (kernel 2.6.26+)
    System Requirements 2GB RAM Recommended, 2Ghz+ CPU Recommended, At least P4-class CPU, Intel Mac Required for OSX Support, USB 2.0 High Speed Port
    Certifications CE, UL
    Cable Length 1.8m (8ft)
    Camera Warranty 1 Year
    Software Support 6 Months
    Compatibility
    Imaging Compatibility (with adapters) 23mm , C-Mount
